Automation Application

Palletizer For Bags Of Syrup

Robotic Palletizing for Cases of Bagged Syrup

This robotic palletizing cell features an automatic pallet dispenser, an activated roller belt sorter, and a high-payload FANUC robot with vacuum tooling designed to pick layers of cases weighing as much as 620+ lbs. An intuitive HMI supports operation, changeovers and troubleshooting. Plus, the cell is also equipped with Remote Access capability.
BF30

BF30-G Bliss Former

Pearson’s BF30-G Bliss Former forms sturdy shipper and display-ready box styles at rates up to 30 cases per minute. This machine is ideal for larger boxes commonly found at club-style stores like Costco or Walmart. An active forming section ensures boxes are secure and consistently square, while an intuitive HMI supports operation, changeovers and troubleshooting. An optional high-capacity Automatic Stack Transfer System is available to decrease the frequency of consumable reloading.
11 14 2023 2 22 54 PM 1

Robotic Palletizing for Bags & Boxes of Pet Food

This robotic palletizing solution handles plastic base sheets, bags, and boxes using custom end-of-arm tooling. (4) FANUC robots share the workload across dual lines, and an intuitive HMI with a pallet configuration tool makes operation, recipe selection, and changeovers a breeze. Plus, the cell is equipped with Remote Access capability for quick troubleshooting and resolution if the need arises.
Scara

Erect, Pack & Seal for Bagged Tortillas

In this application, a Pearson Case Erector and Sealer form consistently square and securely sealed cases. A robotic case packer is designed with a vision system to detect the location of products, and dual Scara robots pack the products into cases. A 2-person handpack station is integrated for small-batch product runs.
CS30 RT 5.1.0 Scaled

CS30-RT Case Sealer

Pearson’s CS30-RT Random Case Sealer offers top and bottom sealing capabilities at high speeds of up to 30 cases per minute. Every case that is introduced into the machine is being measured in height and width to automatically position the folding and sealing mechanism.
4 23 2023 9 31 20 PM

Robotic Partition Inserting with Glue Application & Auto Tool Change

This RPI38 Robotic Partition Inserter accommodates multiple partition and case sizes and features extended magazines, dual robots, and hot melt adhesive application. Automatic tool change is highly accurate and keeps downtime from changeovers to a minimum. An intuitive HMI makes operation and troubleshooting simple, while remote access capability, machine status lighting, and safety redundancy comes standard.
Hqdefault

SS45 Side Sealer

The Pearson SS45 side sealer is ruggedly built and designed to handle bliss boxes and trays at speeds of up to 45 cases per minute. This machine effectively addresses the “flagging” and “skewing” challenges commonly associated with continuous motion sealers. A convenient bypass option eliminates the need for additional conveying when pre-sealed boxes or cases without tops are introduced into the line. And, an intuitive HMI makes operation and troubleshooting simple, while remote access capability, machine status lighting, and safety redundancy comes standard.
IMG 1003 Scaled

Case Erecting, Packing & Sealing for Bundled Tubes

This erect, pack and seal system by Pearson Packaging Systems forms consistently square and securely-sealed cases, and incorporates a vision system and dual delta robots with custom tooling to pack bundles of personal lubricant tubes.
3 20 2023 12 20 51 PM

Robotic Palletizing for HSCs and RSCs

This robotic palletizing cell features automatic pallet dispensing, and a FANUC robot with a custom fork tool, designed to handle both HSCs and RSCs.
RPC PH Thumbnail

RPC-PH Pallet Handling Palletizer

This robotic palletizer automates the pallet load and discharge functions and also handles slip sheets within a compact footprint. The robot can pick and place cases weighing up to 40lbs. at rates up to 12 cases per minute. An intuitive HMI with a pallet configuration tool supports operation, changeovers and troubleshooting, and the cell is also equipped with Remote Access capability.
