RPC-MX

Pearson’s RPC-MX Robotic Palletizer is highly configurable and capable of handling a wide array of product types including cases, trays, totes, bags, pails, drums, or jugs. Using single unit, full row or layer picks, the RPC-MX easily accommodates slow to high-speed, and single to multi-infeed requirements. The end-of-arm tool is configured to the specific application and optimized to guarantee product quality and pallet stability.

All of Pearson’s Palletizers use FANUC robotics with over 80,000 hrs of Mean Time Between Failures (MTBF) for minimal maintenance requirements and the flexibility to easily adapt to new pallet patterns or case sizes, making the cells a reliable choice for high-volume, 24/7 manufacturing and distribution environments. An intuitive user interface (HMI) with integrated pallet configuration tool further simplifies operation and minimizes training needs.

Further optimize your palletizing cell by adding automatic pallet load and discharge function, slip or tier sheet handling, stretch wrapping, or pallet labeling.

Specifications

  • Speed
    • Up to 30 products/min
      *depending on pattern type, case orientation & case weight. Pick count & cell footprint may need to be modified.

  • Operation Robotic
  • Changeover

    Easy-to-use pallet configuration tool to create, modify, copy or clear new pattern recipes on the HMI, optional automatic tool changeover.

  • Controls
    • Allen-Bradley OptixPanel 2800 Color HMI
    • Allen-Bradley PLC
    • Fanuc Robot Controller
    • PackML Compliant
  • Air Requirements 80 PSI
  • Power Requirements 460 VAC
  • Disconnect Sizes 30-60 Amps
  • Infeed Single or multiple infeed with sorting capabilities, low and high-level options
  • Outfeed Single or multiple outfeed with or without conveyance
  • Pallet Height Up to 108 in
  • Pallet Handling
    • Pallet conveying
    • Pallet discharge
    • Pallet stack transfers
    • Static magazine
  • Product Weight Up to 125 lbs
  • Guarding Fencing, Light Curtains or Area Sensors

User Centric Design

User centric design is about making the interaction with our machines as intuitive as possible. We want to reduce the learning curve for operators and maintenance technicians, make it easy to interpret data from the machine into actionable information, minimize the margin for human errors and make set up, changeover and fault recovery a faster and more seamless process resulting in improved up time and equipment availability.

Popular Upgrade Options

Automatic Pallet Handling

Automatic pallet discharge and/or pick and placement and conveying to the pick station and out of the cell.

Bar Code Reader

Also known as a barcode scanner, integrating a bar code reader enables the automatic identification and tracking of pallets and their contents, for faster processing, reduced errors, and improved inventory management.

Check Weighing

Ensure each palletized load, or individual packages before palletizing, meets a specified weight requirement, preventing underweight or overweight shipments.

Low or High Temperature Package

Electrical enclosures located in cold and humid environments maintain better performance and longevity with the addition of a heater and drier package. In high-temperature environments, the addition of an air conditioner may be necessary for optimal performance.

Metal Detector

Detect metal contaminants in products before they are stacked on pallets, ensuring product safety and preventing damage to equipment.

Pallet Labelers

Quickly and accurately label pallets on one or multiple sides with information like product details, barcodes, and shipping instructions.

Pallet Strappers

Integration of a strapping machine, that automatically applies straps around the loaded pallet to hold the stacked products securely.

Plant Level Ethernet Connection

A Network Address Translation device allows specific Ethernet network configurations across multiple machines in the plant network and offers the ability for remote support through VPN connections.

Slip or Tier Sheet Insertion

Integration of slip or tier sheet dispensing and placement between layers of product, ensuring stability and preventing damage during handling and storage.

Stretch Wrap Integration

Integrated stretch wrapping to secure palletized load for transport and storage. Stretch wrapping can be added into the stacking process or after the pallet is completed.

Washdown Requirements

Upgrade package for non-caustic, non-clean environments protecting against low-pressure jets of water from all directions.

Videos

Robotic Palletizing RPC MX for Open Trays with Bottle Caps

A FANUC robot with uptime averaging 80,000+ MTBF and an end-of-arm tool that handles pallets, slip sheets, and trays. An intuitive HMI supports operation, recipe selection and troubleshooting. Plus, the cell is also equipped with Remote Access capability.

Robotic Palletizing RPC with Shelf-Gripper Tooling

This robotic palletizing cell has an automatic pallet dispenser that is compatible with a variety of pallet types, and it uses a shelf gripper tool with retractable forks to scoop and release up to 10 cases at a time. It’s intuitive HMI supports operation, recipe selection, and changeovers. Plus, the cell is equipped with Remote Access capability.

Dual Station RPC with Case Sweep

This robotic palletizer with dual build stations uses a multi-functional end-of-arm tool to pick pallets, slip sheets, and rows of cases. In addition to a pneumatic case sweep, is also has an intuitive HMI with a pallet configuration tool to support operation, changeovers and troubleshooting. Plus, the cell is equipped with Remote Access capability.

Dual Robotic Palletizing System – Large Bags of Kitty Litter

This dual robotic palletizing system stacks large 25lbs. and 40lbs. bags of kitty litter. The system includes a pallet dispenser and slip sheet application.

Robotic Palletizer – Pails of Kitty Litter

In this palletization application, Pearson robotically stacks pails of Kitty Litter. The system provides ergonomically safe, efficient and reliable operation.

Robotic Palletizer – Boxes of Chips

This robotic palletizing cell stacks corrugated boxes of chips. To increase speed, the robot stacks three cases at a time for a full row. The system includes a pallet dispenser.
