RDPC-MX Robotic Depalletizer

Home » Equipment » Equipment » RDPC-MX Robotic Depalletizer
Depal

Pearson’s RDPC-MX Robotic Depalletizer is highly configurable and capable of handling a wide array of product types including RSC and HSC cases, pails, drums, jugs, jars and bottles up to 125 lbs and speeds of up to 30 products per minute.

All of Pearson’s Palletizers and Depalletizers use FANUC robotics with over 80,000 hrs of Mean Time Between Failures (MTBF) for minimal maintenance requirements and the flexibility to easily adapt to new pallet patterns or case sizes, making the cells a reliable choice for high-volume, 24/7 manufacturing and distribution environments. An intuitive user interface (HMI) further simplifies operation and minimizes training needs.

Configure the system to your specific needs with single or multiple depalletizing stations, single or multiple outfeeds, bar code reading, automatic pallet handling, and various fencing options.

Specifications
User Centric Design
Upgrade Options
Videos
Get A Quote

Specifications

  • Products

    • Bottles

    • Drums

    • HSC Cases

    • Jugs

    • Pails

    • RSC Cases
  • Speed

    • Up to 30 products/min
      *depending on pattern type, case orientation & case weight. Pick count & cell footprint may need to be modified.
  • Infeed Single or Multiple Stations
  • Pallet Height Up to 108 in
  • Operation Robotic
  • Changeover

    Easy-to-use pallet configuration tool to create, modify, copy or clear new pattern recipes on the HMI, optional automatic tool changeover.
  • Controls
    • Allen-Bradley OptixPanel 2800 Color HMI
    • Allen-Bradley PLC
    • Fanuc Robot Controller
    • PackML Compliant
  • Guarding Fencing, Light Curtains or Area Sensors
  • Air Requirements 80 PSI
  • Power Requirements 460 VAC
  • Disconnect Sizes 30-60 Amps

User Centric Design

User centric design is about making the interaction with our machines as intuitive as possible. We want to reduce the learning curve for operators and maintenance technicians, make it easy to interpret data from the machine into actionable information, minimize the margin for human errors and make set up, changeover and fault recovery a faster and more seamless process resulting in improved up time and equipment availability.

More Information

Popular Upgrade Options

Automatic Pallet Handling

Automatic pallet discharge and/or pick and placement and conveying to the pick station and out of the cell.

Bar Code Reader

Also known as a barcode scanner, integrating a bar code reader enables the automatic identification and tracking of pallets and their contents, for faster processing, reduced errors, and improved inventory management.

Low or High Temperature Package

Electrical enclosures located in cold and humid environments maintain better performance and longevity with the addition of a heater and drier package. In high-temperature environments, the addition of an air conditioner may be necessary for optimal performance.

Plant Level Ethernet Connection

A Network Address Translation device allows specific Ethernet network configurations across multiple machines in the plant network and offers the ability for remote support through VPN connections.

Washdown Requirements

Upgrade package for non-caustic, non-clean environments protecting against low-pressure jets of water from all directions.

Videos

Robotic Depalletizing for Glass Jars

In this robotic depalletizing application, two robots handle pallets, empty trays, slip sheets, and glass jars.
Watch Video
